Fully automatic pet blowing machine can produce all kinds of plastic bottles. It has an advanced control system to automate the entire production process of finished plastic bottles.YG offers automatic blowing machines that precisely control every step of the operation through pre-set programs and parameters. This ensures that the plastic bottles produced are of consistent quality, shape, and size. We have different models of fully automatic blowing machines. Please click to get a competitive price for the equipment!
Parameters of automatic pet blowing machine
| Model | YG-1H-3L | YG-1H-5L | YG-2H-1.25L |
| Production Capacity | 1 cavity | 1 cavity | 2 cavity |
| Theoretical output(PCS/H) | 600-800 | 500-600 | 1500-2000 |
| Pressure for blowing(KG) | 30 | 30 | 30 |
| Flow rate for working(m³) | 0.8 | 1 | 0.8 |
| Flow rate for blowing(m³) | 0.8 | 1 | 0.8 |
| Neck diameter(MM) | 12-80 | 50-110 | 12-30 |
| Max diameter&height(MM) | 120*200 | 150*280 | 80*300 |
| Machine size(M) | 2.6*1.6*1.8 | 2.7*1.6*1.8 | 2.6*1.5*1.8 |
| Machine weight(KG) | 1800 | 1800 | 1800 |
bottle blow molding machine’s Finished products
The maximum output of the automatic pet blowing machine can be mineral water bottles, oil bottles, warm irrigation bottles, soda bottles, fruit juice bottles, aerated beverage bottles, wine bottles; seasoning bottles such as soy sauce, vinegar, etc.; cosmetic bottles, disinfectant bottles, hand sanitizer bottles, and other PET bottles. It can be widely used in the beverage, food, cosmetic, medical, and chemical industries.
water bottle blowing machine Working Principle
1. The heated oven heats the preforms through infrared lamps, and the reflector makes both sides of the preforms heated evenly through reflection. The preforms will rotate automatically, while the cooling system will cool down the bottle mouth.
2. Blowing system: The blowing system is to blow the preforms into bottles, which consists of a stretching device and mold closing device.
3. Bottle blowing machine through pre-blowing, high blowing, stretching blowing, exhausting finally blowing the preforms into bottles.
Main Features of automatic Pet bottle blower
1. Low cost. The cost of an automatic pet blowing machine is not high, which is suitable for customers who have little investment and are new to the industry.
2. Unique clamping frame double protection: First, the guide rail is equipped with safety valve value electronic components. 3 3. Secondly, there is a mechanical limit block at the end of the guide rail, which can prevent the mold-locking arm from falling off.
4. Fine machining inside the die head, smooth flow without dead space accumulation of material.
5. Optimized hydraulic oil circuit design, power saving, fast action, and convenient parameter adjustment.
6. The frequency conversion speed control extrusion motor can adapt to the requirements of the blow molding process on the screw speed change.
7. The machine can set different die heads for customers to choose according to the product characteristics.
Precautions for the use of a Bottle blow molding machine
1. Preparation before production
1.1 Check the automatic pet blowing machine for any damage to parts and components. Check whether there is debris in the extruder hopper and clean it up, then close the material gate.
1.2 Check whether the moving parts are firm and whether the screws are loose. Especially the part with a strong impact. Whether the belt drive part is abnormal.
1.3 Check whether the high-pressure gas source, low-pressure gas source, power supply, and water source are normal.
1.4 Check whether each emergency stop switch, safety door switch, or protection device detection switch is normal.
1.5 Check whether each pneumatic component is leaking air and whether the action is sensitive.
1.6 Please operate strictly according to the procedure of the operation manual.
2. Normal production
When the machine is in normal production, there should be a person in charge of looking after the machine, so that problems can be found and dealt with in time. Automatic blow molding machine has a high degree of automation, users only need to add raw materials regularly. And collect the products in the designated position of the machine can be.
plastic bottle blowing machine price from YG
YG provides fully automatic pet blowing machines. Different models of automatic bottle blowing machines can meet the output requirements of different customers. We also produce semi-automatic bottle blowing machines. He needs more manual operation. We will recommend the right equipment according to your budget.YG As a professional plastic products manufacturer, we also provide blow molding machines, plastic bag machines, plastic straw machines, and other related equipment. The automatic blow molding machine is good and the low price is excellent plastic bottle production equipment. Contact us for more equipment information!
