PP woven bag printing machine is mainly used to print on top of PP woven bags. It can work according to the pattern and text you set. The machine works efficiently with a continuous printing function. Meanwhile, it adopts advanced anilox rollers which can realize uniform ink transfer and clear printing effect.YG offers you different models of PP woven bag printing machines, which can realize printing 1-6 colors. Click to buy the PP woven bag printing machine model that suits you!
PP woven bag printing machine Parameters
| Model | YG-840Ⅱ | YG-840Ⅲ | YG-840Ⅳ |
| Most greatly entering machine width | 800mm | 800mm | 800mm |
| Maximum printing width | 650mm | 650mm | 650mm |
| Rubber relief printing thickness | 4-6mm | 4-6mm | 4-6mm |
| Biggest printing length | 1200mm | 1200mm | 1200mm |
| India roller diameter | 430mm | 430mm | 430mm |
| Printing color | 1500-3500pcs/h | 1500-3500pcs/h | 1500-3500pcs/h |
| Printing color | 1 Color | 2 Color | 3 Color |
| Electrical machinery power | 0.75kw | 1.5kw | 1.5kw |
| Installs the size | 900*1400*1200 | 1400*1400*1200 | 2000*1400*1200 |
| Gross weight(approximate | 1500kg | 2000kg | 2500kg |
Application range of PP bag printing machine
The specific items that can be printed by PP woven bag printing machines are mainly focused on a variety of products that require the use of PP woven bags as packaging materials. For example, rice, flour, fertilizer bags, feed, cement, sand, seeds, spices, plastic pellets, and other PP woven bags. These PP woven bags have a wide range of applications and good market prospects.
PP Woven Bags Printing Machine working principle
The whole working process of the PP woven bag printing machine is simple. The working principle is as follows:
- Plate making: first, the text and images to be printed are made into plates.
- Inking: Then, the ink is applied to the place where there are words and images on the printing plate either manually or by machine.
- Printing: Then, through the pressure of the printing machine, the ink on the printing plate is transferred to the PP woven bag to complete the printing process.
5 features pP woven bag printing machine
- PP woven bag printing machine uses pneumatic separation, low noise, and more energy saving.
- This woven bag printing machine adopts an advanced anilox roller and an automatic ink pump printing ink circulation system. It makes the ink more even and plump, and the printing smoothness is enhanced.
- Automatic counting linkage work, the counter can be set according to the requirement of printing quantity.
- Mesh roller transfer printing ink, the ink color is even.
- The device automatically adjusts the speed of the magnetic motor to adapt to different printing speeds.
pP woven bags printing machine price from YG
YG offers PP woven bag printing machines with low prices, good quality, and accurate printing effect, which is the necessary equipment for PP woven bag manufacturing industry. In addition to woven bags, this equipment can also print on non-woven fabrics and other bags for packaging grain. Therefore it has a wide range of applications. In addition to the woven bag printing machine, we also produce woven bag machines, cutting and sewing printing production lines,s and other related equipment. We also produce a flexible printing machine which is specialized in printing on plastic bags. Our printing machines can print on many different materials. Please let us know your requirements so we can get information about our machines!
